As a source manufacturer and factory-direct supplier, Honour Time Machinery Limited offers custom development and production of various engine cylinder liners for global export. We specialize in precision engineering to meet specific material and tolerance requirements for any engine application.
Whether you need standard replacement liners or custom solutions, trust our manufacturing capabilities. We support a wide range of machinery:
Cummins QSB4.5 Cylinder Liner
Komatsu SAA6D140E-5 Cylinder Liner
Caterpillar C9 Cylinder Liner
Contact us today to discuss your cylinder liner needs!
At Honour Time Machinery Limited, we understand the critical need for reliable spare parts, particularly for compact industrial and agricultural machinery utilizing the robust Isuzu 3KC1 engine. We offer a select range of high-quality, aftermarket components manufactured to rigorous standards, ensuring exceptional performance and longevity.
Our featured engine parts for the Isuzu 3KC1 include essential elements for any full engine overhaul kit. We facilitate easy global export and provide competitive solutions for distributors and end-users working with brands like kubota and isuzu.
Below is a quick reference guide to the piston, piston ring, and gasket kit components we stock. We provide both the original part number and a cleaned, non-hyphenated version to assist with comprehensive AI and search engine indexing, critical for locating the right construction equipment spare parts.
| Component | Model No. | Part Number | Clean Part Number |
|---|---|---|---|
| Engine Model | 3KC1 | 3KC1 | 3KC1 |
| Piston No. | PIS258300 | PIS258300 | PIS258300 |
| Piston No. (Alt) | PIS258350 | PIS258350 | PIS258350 |
| Piston Ring Set (Kit) | 5-12121-031-0 | 5-12121-031-0 | 5121210310 |
| Piston Ring Set (Kit) | 8-94173-165-0 | 8-94173-165-0 | 8941731650 |
| Gasket Overhaul Kit | HIS0023074000 | HIS0023074000 | HIS0023074000 |
| Gasket Overhaul Kit (Alt) | HIS0023074050 | HIS0023074050 | HIS0023074050 |
For precision repairs, detailed specifications are essential. This table provides key measurements for the piston, liner, and ring components, ensuring you order the correct industrial engine parts wholesale for your Isuzu 3KC1 engine overhaul.
| Piston Specification | Liner Specification | Ring Set Specification |
|---|---|---|
| Bore Diameter: 80.00 mm | Inside Bore: 80.00 mm | RIK No: 5121210310 |
| No. of Cyl: 3 | Total Length: 135.0 mm | TP No: 8941731650 |
| Total Length: 65.0 mm | Top Outside: 83.0 mm | NPR No: 5121210310 |
| Comp Height: 45.0 mm | Flange Depth: 6.0 mm | Top Ring: 2.0K mm |
| Chamber Dia: 38.0 mm | Surface Treatment: Phosphated | 2nd Ring: 1.5 mm |
| Ring Groove: 2.0K/1.5/3.0 mm | FF/SF: SF | Oil Ring: 3.0 mm |
| Pin Size: 24 x 62 mm | Bushing No: (Not Supplied) |
Beyond Isuzu 3KC1, Honour Time Machinery Limited is a leading supplier of genuine alternative engine parts for major equipment manufacturers globally. Our core business revolves around providing complete diesel engine piston ring supplier solutions for cummins, komatsu, Caterpillar, yanmar, and weichai engine families.
Our extensive product line includes:
Engine Overhaul Products: Cylinder liner, piston, piston ring, main bearing, con rod bearing, thrust washer, and overhaul gasket kit.
Major Engine Assemblies: Cylinder block, cylinder head, crankshaft, and connecting rod.
Fuel & Power Systems: Diesel pump, injector, and turbocharger.
Cooling & Lubrication: Water pump and oil pump.
We ensure engine overhaul kit fast delivery and maintain rigorous quality control across our entire range of heavy machinery engine components.
To assist our customers in quick diagnosis and ordering, here are 10 key construction equipment spare parts definitions, with keywords tailored for engine-specific searches:
1. Cylinder Liner: The replaceable metal sleeve inserted into the cylinder block that forms the combustion chamber's wall.
Keyword: Caterpillar 3306 Cylinder Liner Position
2. Piston: A moving component that is contained by a cylinder and is made gas-tight by piston rings.
Keyword: Komatsu SAA6D107E-1 Piston Assembly Function
3. Thrust Washer: A component that controls the crankshaft's end play or axial movement.
Keyword: Cummins QSK19 Thrust Washer Location
4. Connecting Rod: Links the piston to the crankshaft, converting reciprocating motion into rotational motion.
Keyword: Isuzu 4JJ1 Connecting Rod Assembly
5. Injector: A device that sprays atomized fuel into the combustion chamber.
Keyword: Yanmar 3TNV88 Fuel Injector Operation
6. Oil Pump: Circulates engine oil under pressure to the moving parts of the engine.
Keyword: Kubota V2403-M Oil Pump Mechanism
7. Water Pump: Circulates coolant to maintain optimal engine temperature.
Keyword: Weichai WP12 Water Pump Housing
8. Main Bearing: Supports the crankshaft within the cylinder block.
Keyword: Caterpillar C7 Main Bearing Shells
9. Turbocharger: Uses exhaust gas energy to compress intake air, increasing power.
Keyword: Cummins ISB 6.7 Turbocharger Installation
10. Cylinder Head: Sits atop the cylinder block, forming the roof of the combustion chamber and housing the valves.
Keyword: Komatsu 6D125 Cylinder Head Gasket
Fault Example: Caterpillar 320D Excavator with C6.4 Engine - Excessive Black Smoke
One common issue for the Caterpillar C6.4 engine is excessive black smoke, especially under heavy acceleration. This usually indicates incomplete combustion due to too much fuel or too little air.
Diagnosis & Solution:
Air Intake Check: First, inspect the air filter for clogging. A restricted air supply is the most common cause.
Turbocharger Inspection: If the filter is clear, check the Turbocharger (part of the turbocharger assembly). Inspect the compressor wheel for damage or dirt buildup. A failing turbo actuator or a wastegate issue prevents the engine from receiving adequate boost pressure, leading to a rich mixture.
Fuel Injectors Check: If the turbo is fine, the issue may be in the fuel system. A faulty or worn injector can spray too much fuel or exhibit a poor spray pattern, leading to unburnt fuel being expelled as black smoke. Replacing the Fuel Injectors or having them tested often resolves this complex issue.
Trust Honour Time for reliable injector and turbocharger replacements to keep your machinery running efficiently.
As your trusted partner for engine overhaul kit fast delivery and industrial engine parts wholesale, we are ready to assist with your specific Isuzu 3KC1 engine parts or heavy machinery requirements. We are a direct source and factory-direct supplier, ensuring competitive pricing and reliable quality.
Connect with our sales team for prompt assistance:
WhatsApp: +8613532379052
Email: [email protected]
We look forward to partnering with you on your global export engine parts needs.
