Welcome to Honour Time Machinery Limited, the reliable engine parts supplier dedicated to providing OEM-quality and aftermarket solutions for the world's leading heavy machinery. We specialize in components for cummins, komatsu, Caterpillar, isuzu, kubota, yanmar, and weichai engine assemblies. Our featured product line includes vital parts for the powerful ISUZU 10PE1 engine, ensuring your industrial diesel engine repair or rebuild is completed with precision and durability.
As a custom cylinder liner manufacturer and source factory, we offer factory-direct sales and export-grade solutions. Beyond standard supply, we support comprehensive customization for various engine models.
We can custom-develop cylinder liners for applications like:
CATERPILLAR 3406 Liner
KOMATSU S6D105 Liner
CUMMINS N14 Cylinder Liner
We provide the complete set of internal components for the ISUZU 10PE1 engine assembly. Ensuring you receive genuine ISUZU piston ring set and high-precision liners is our top priority for your complete engine gasket kit or full overhaul. Below are the key components and their specifications, essential for any heavy-duty truck engine components maintenance project.
| Component | Part No. (With Hyphen) | Part No. (Without Hyphen) | Key Spec | Detail | |
|---|---|---|---|---|---|
| Engine Model | 10PE1 | 10PE1 | No. of Cyl | 10 | |
| Piston No. | 1-12111-676-0 / 1-12111-926-0 | 1121116760 / 1121119260 | Bore Diameter | Approx 140 mm | |
| Cylinder Liner No. | 1-11261-175-1 | 1112611751 | Total Length | Approx 260 mm | |
| Piston Ring Set No. | 1-12121-129-1 | 1121211291 | Top Ring | Keystone Type | |
| Piston Pin Size | Approx 55 mm | Pin Size | Approx 55 mm x 100 mm | Bushing No. (for Con Rod) | 1-12171-081-0 |
| Piston Comp Height | Approx 80 mm | Liner Flange Depth | Approx 5 mm | Ring Groove | 3 Grooves |
| Piston Chamber Dia | Approx 85 mm | Liner Surface Treatment | Honing/Phosphate | RIK No. | 22530 |
| Liner Inside Bore | Approx 140 mm | Liner Total Length | Approx 260 mm | TP No. | 40605 |
| Liner Bottom Outside | Approx 150 mm | Liner Top Outside | Approx 155 mm | NPR No. | SWA30067 |
At Honour Time, we provide a massive inventory for all major engine systems. From best price crankshaft china to full engine rebuild kits, we cover every component. Our main products include: cylinder liners, pistons, piston rings, crankshaft bearings, connecting rod bearings, thrust washers, overhaul kits, diesel pumps, injectors, crankshafts, turbochargers, water pumps, oil pumps, engine blocks, cylinder heads, and connecting rods.
We are proud to be a reputable engine spare parts exporter, specializing in off-highway engine overhaul and excavator engine maintenance. We offer OEM quality engine bearings for critical applications and support agricultural machine engine parts. We ensure all parts meet the demands of heavy equipment diesel pump operation. Contact us for the most affordable CATERPILLAR injector or for your WEICHAI engine assembly rebuild project. We aim to be your sole supplier for all engine parts, including KUBOTA compact tractor parts and marine engine components.
Piston: Located in the cylinder block, converts combustion energy into mechanical motion. E.g., CUMMINS QSB6.7 Piston.
Cylinder Liner: Installed inside the cylinder block, acts as the wear surface for the piston. E.g., KOMATSU SAA6D140E Liner.
Turbocharger: Mounted on the exhaust manifold, boosts engine power by forcing air into the cylinders. E.g., CATERPILLAR C9 Turbocharger.
Connecting Rod: Connects the piston to the crankshaft, found within the crankcase. E.g., ISUZU 6BG1 Connecting Rod.
Main Bearing: Located in the engine block's main journals, supports the crankshaft. E.g., KUBOTA V3800 Main Bearing.
Fuel Injector: Installed in the cylinder head, sprays fuel into the combustion chamber. E.g., YANMAR 4TNV98 Injector.
Water Pump: Attached to the engine block, circulates coolant throughout the cooling system. E.g., CUMMINS ISX15 Water Pump.
Oil Pump: Located in the oil pan or engine block, pressurizes and circulates engine oil. E.g., WEICHAI WP10 Oil Pump.
Cylinder Head Gasket: Sealing component placed between the cylinder head and the engine block. E.g., CATERPILLAR 320D Gasket.
Crankshaft: Located in the lower part of the engine block, converts linear motion into rotational motion. E.g., KOMATSU PC200-8 Crankshaft.
Fault: A severe overheating issue observed on an ISUZU CXZ81K Truck Engine Assembly operating under load.
Inspection & Diagnosis: Initial inspection revealed low coolant, but after replenishment, the engine still ran hot, and the coolant quickly disappeared. A pressure test of the cooling system showed a rapid drop, indicating an internal leak. Oil analysis showed coolant contamination. This pointed to a failure in the Cylinder Head Gasket or a cracked cylinder head/liner.
Solution: The engine was partially disassembled, and the cylinder head gasket was found to have a breach between a combustion chamber and a coolant passage. The solution involved replacing the entire complete engine gasket kit, ensuring the cylinder head surface was properly milled and flat, and re-torquing the cylinder head bolts to factory specifications. This preventative measure ensures engine reliability and prevents long-term damage from contaminated oil.
Connect with our team for OEM quality engine components, competitive pricing, and global shipping expertise. We are the source for your high-quality KOMATSU water pump, YANMAR mini excavator turbocharger, or any other engine part need.
