Hx35W Turbo 4038471 3598036 4035375 4089746 4089136 Turbocharger for Cummins Komatsu Truck, Excavator PC220

Part Number: 4038471

Interchangeable Number: 3595159,3598036,4035375,4035376,4035376HOEM Number:4089136,4089746,6738-81-8190,6738818190,6738-81-8191,6738818191,6738-81-8192,6738818192Turbo Model: HX35W,HX35W-E7735L/E12PB11

Manufacturer: Holset

Year: 2001-04

Engine: 6B,6BTAA,6BTA5.9-C169,SAA6D102E-2

Engine Manufacturer: Cummins, KCEC

Displacement: 5.9L, 5900 ccm

Fuel: Diesel

Angle a (Compressor Housing): 160

Angle β (Turbine Housing): 20°

Actuator Kit (Pneumatic):4030123H/4031488H

Bearing Housing: 3532632/4027869

Bracket Kit: 4027137H

CHRA:4027883(4027883H)

Clamp Plate (Turbine):2839879H

Compressor Wheel: 3599639 (Ind. 50 mm, Exd. 83 mm, 8+8 Blades)

Gasket (Oil Drain):3519805H

Gasket (Oil 0utlet):210060(311585,148062)(Paper)

Gasket (Turbine inlet): 409039-0000 (inox Steel)(409039-0001,210019,2405022)(1900000006)

Gasket (Turbine Outlet):3535001H

Gasket Kit: 3545575H

Heat Shield:3519304(3519302)(1152301340)

Repair Kit (Maior):3575169(3575169H)(1153035750)

Retaining Ring: 3533163H

Seal Plate: 3530923 (1154351300)

Turbine Housing: 3532299H

Turbine Wheel: 3519336 (ind, 70 mm, Exd, 59,9 mm, 12 Blades)(1152301435)Turbocharger Kit: 4035376H

NOTE: Interchangeable with 5328623 but with compressor housing angle rotated.

Application:

2001-04 Komatsu PC220 Excavator with KCEC 6B, 6BTAA Engine2001-04 Komatsu PC220,PC270 Excavator with Cummins 6BTA5.9-C169, SAA6D102E-2 EngineHyundai R210W-9S,R260LC-9S Excavator
